70402 Non-Cyanide Gold Plating Process
Description:
| Lead Time | 10 - 15 days |
Quick Details
| Eco-Friendly | Environmentally Safe | High Conductivity | Efficient Conductance |
| Corrosion Resistance | Anti-Tarnish | Aesthetic Appeal | Decorative Finish |
| Wide Industry Application | Versatile Use |
Product Details
Characteristics:
1. 70402 Imitation Gold Process can plate bright and beautiful 18~24K gold colour.
2. Cyanide-free additives, simple makeup, easy control with excellent stability.
3. Widely use for plating on metal hardware, jewelries, watches, spectacles, lighting fixtures,
buckles and hook accessories.
4. Suitable to operate by both rack and barrel plating.
Composition and operating condition:
| Composition | Operating Parameters | Rack Plating | Barrel Plating |
| 70402M Makeup Salt | 160 ~ 200g/L | 180 g/L | 160 g/L |
| 70402H Adjustor | 35 ~ 45 g/L | 40 g/L | 35 g/L |
| Temperature | 30 °C ~ 40 °C | 35 °C | 35 °C |
| Density | 14 ~ 18 ºBe | 16 ºBe | 14 ºBe |
| pH | 9 ~ 10 | 9.5 | 9.5 |
| Voltage | 3 ~ 8 V | 5 V | 7 V |
| Current density | 0.1 ~ 1 A/dm² | 0.5 A/dm² | 0.5 A/dm² |
| Anode | 316 Stainless steel panels | ||
| Anode to cathode ratio | 4 ：1 | ||
| Filtration | Continuous filtration with 10 microns filter cartridges | ||
| Heating equipment | Stainless steel heater | ||
